Hougen  |  SKU: 0905102

HMD905 Two Speed Magnetic Drill

$2,825.00 CAD

Hougen HMD905 Magnetic Drill

Model

Delivery and Shipping

Standard shipping rates apply.

Description

HMD905 Two Speed Magnetic Drill - 250 & 450 RPM

The mag drill of choice for fabrication. Lightweight, compact, powerful, and versatile.

A powerful two speed mag drill with great power to weight ratio.

  • Large 2″ x 2″ capacity
  • Powerful high torque Hougen motor and gears
  • Two Speed gear box – 250 & 450 RPM
  • Pilot light
  • Two stage magnet – 30% increase in power when motor is turned on
  • Positive slug ejection
  • Integrated coolant bottle
  • Many accessories are available for a portable machine shop including: drill chucks, tapping, countersink, and more…
  • Feed handles quickly change from side to side
  • Lift detector safety system
  • Rear mounted controls
  • Carrying case included
  • Two year warranty

Optional Swivel Base adds even greater versatility:

  • Precisely line up your pilot with the holes center location
  • One stroke lock and unlock handle
  • Great for horizontal, overhead, tight areas, and getting out over another piece of steel
  • Patented



Specifications

  • Power Supply Voltage
    115V, 50/60 Hz - 10A, 1150W
  • Motor
    9A (115V), 250/450 RPM
  • Diameter
    7/16"- 2" (12mm - 50mm)
  • Depth
    2" (50mm)
  • Cutter
    "12,000-Series" & Copperhead™ Carbide cutters, 3/4" shank
  • Dimensions
    22-13/16" H x 7-11/16" W x 11-3/4" L
  • Magnet
    BASE: 3-1/8" W x 6-9/16" L (79mm W x 167mm L)
  • Weight
    35 lb. (15.9 kg)
  • Shipping Weight
    52 lb (23.6 kg)
