TECNA Long-Travel Zero-Gravity Balancers
Description
Description
TECNA long-travel zero-gravity balancers are for applications where a standard vertical stroke does not cover the full work envelope.
When long travel matters
They are suited to tall workpieces, large fixtures, extended-reach stations and suspended equipment that must move through a greater vertical distance.
How to select
Start with the complete suspended load, then choose a model whose rated working range contains that load and whose available stroke covers the actual movement required.
Technical reference: TECNA manufacturer data. Final selection must match the complete suspended load, stroke, environment and required configuration.
Where long travel is useful
- 20–30 kg: long-reach welding/assembly tools and suspended tooling around tall workpieces.
- 30–70 kg: heavy production tooling, welding guns and process heads requiring more vertical movement.
- 70 kg+: large suspended equipment where both load capacity and an extended work envelope matter.
Choose this family when
The load range is correct but a standard stroke does not cover the actual vertical work area. Measure the required travel before choosing the model.
Selection support
Choose by load, travel and environment
A spring balancer is selected by its rated working range, not simply the largest number in the product name. Use the complete suspended load, then confirm stroke, environment, rope or hose type, mounting geometry and any application-specific requirements before choosing the exact model.
Canadian ergonomics reference: CCOHS recommends tool balancers to reduce the effort of holding and operating tools, and Government of Canada guidance notes that frequently used heavy tools can be suspended to help support and counterbalance their weight. CCOHS ↗ Canada.ca ↗
Include the tool, accessory, hanger and any supported hose or cable contribution.
Match stroke to the real vertical working area so the tool stays usable throughout the task.
Confirm standard, washdown, ESD, ATEX-family or outdoor/cold-weather requirements.
Picture the load
What could this balancer family support?
These are representative application examples, not model approvals. Actual tools vary widely in weight, battery, socket, hose and accessory configuration. Always weigh the complete suspended assembly and match it to the manufacturer's published working range.
TECNA identifies tools, fixtures, welding guns, hoses, pipes, charging connectors, cables and suspended equipment among spring-balancer applications. Manufacturer application overview ↗
Compare every model in this family23 configurations
Compare rated range, travel/configuration, SKU and price in one place. The variant title contains the load range and configuration exactly as it is sold.
| Rated range / travel / configuration | SKU | Price |
|---|---|---|
| 44.1–66.1 lb (20–30 kg) / 83 in (2100 mm) / Standard | TE9502 | $1,547.70 CAD |
| 88.2–110.2 lb (40–50 kg) / 98 in (2500 mm) / Standard | TE9404 | $2,286.90 CAD |
| 110.2–132.3 lb (50–60 kg) / 98 in (2500 mm) / Standard | TE9405 | $2,371.60 CAD |
| 33.1–44.1 lb (15–20 kg) / 98 in (2500 mm) / Standard | TE9401 | $2,132.90 CAD |
| 33.1–44.1 lb (15–20 kg) / 98 in (2500 mm) / Floor lock | TE9401.B | $2,217.60 CAD |
| 33.1–44.1 lb (15–20 kg) / 98 in (2500 mm) / Enhanced floor lock | TE9401.B1 | $2,333.10 CAD |
| 33.1–44.1 lb (15–20 kg) / 98 in (2500 mm) / Rubber-covered | TE9401G | $2,564.10 CAD |
| 33.1–44.1 lb (15–20 kg) / 98 in (2500 mm) / Rubber-covered + floor lock | TE9401G.B | $2,656.50 CAD |
| 33.1–44.1 lb (15–20 kg) / 98 in (2500 mm) / Rubber-covered + enhanced floor lock | TE9401G.B1 | $2,779.70 CAD |
| 44.1–66.1 lb (20–30 kg) / 98 in (2500 mm) / Standard | TE9402 | $2,186.80 CAD |
| 44.1–66.1 lb (20–30 kg) / 98 in (2500 mm) / Floor lock | TE9402.B | $2,271.50 CAD |
| 44.1–66.1 lb (20–30 kg) / 98 in (2500 mm) / Enhanced floor lock | TE9402.B1 | $2,394.70 CAD |
| 44.1–66.1 lb (20–30 kg) / 98 in (2500 mm) / Rubber-covered | TE9402G | $2,625.70 CAD |
| 44.1–66.1 lb (20–30 kg) / 98 in (2500 mm) / Rubber-covered + floor lock | TE9402G.B | $2,718.10 CAD |
| 44.1–66.1 lb (20–30 kg) / 98 in (2500 mm) / Rubber-covered + enhanced floor lock | TE9402G.B1 | $2,841.30 CAD |
| 66.1–88.2 lb (30–40 kg) / 98 in (2500 mm) / Standard | TE9403 | $2,240.70 CAD |
| 66.1–88.2 lb (30–40 kg) / 98 in (2500 mm) / Floor lock | TE9403.B | $2,325.40 CAD |
| 66.1–88.2 lb (30–40 kg) / 98 in (2500 mm) / Enhanced floor lock | TE9403.B1 | $2,448.60 CAD |
| 66.1–88.2 lb (30–40 kg) / 98 in (2500 mm) / Rubber-covered | TE9403G | $2,695.00 CAD |
| 66.1–88.2 lb (30–40 kg) / 98 in (2500 mm) / Rubber-covered + floor lock | TE9403G.B | $2,764.30 CAD |
| 66.1–88.2 lb (30–40 kg) / 98 in (2500 mm) / Rubber-covered + enhanced floor lock | TE9403G.B1 | $2,895.20 CAD |
| 88.2–110.2 lb (40–50 kg) / 98 in (2500 mm) / Floor lock | TE9404.B | $2,371.60 CAD |
| 88.2–110.2 lb (40–50 kg) / 98 in (2500 mm) / Enhanced floor lock | TE9404.B1 | $2,494.80 CAD |
Documentation, parts & fleet support
Buying the balancer is only the first step.
TECNA publishes current user manuals by model family and specifies original TECNA spare parts for maintenance. If you are replacing or maintaining an installed unit, send us the model and identification-plate information so the request can be tied to the correct family.
More than one workstation?
Do not quote the shop one balancer at a time.
Send the full tool list and quantities. We can consolidate the selection by station, identify where models can be standardized, and review current project pricing and lead times as one package.
Tell us the exact tool or load.
Send the tool make/model, complete suspended weight, required travel and environment. We can confirm which rated range and configuration actually fits.
